Product Passport reader KR500(C) ID Card Scanner

Function Introduction

Identify cards

Supports the reading of more than 80 kinds of cards including domestic and foreign driver's licenses and ID cards. And support reading smart card complied with ISO/IEC 7816

Identify passports

Support reading ICAO doc 9303 standard multi passports, such as e-passports and passports from more than 200 countries

Reading methods

Support three reading methods: pure photo OCR recognition, pure card reading, photo + card reading

Multispectral imaging

Passport reader supports output of visible light, infrared light, ultraviolet light image

Extract avatars

The passport reader supports the extraction of personal avatars and chip avatars on the surface of documents

Support certificate authenticity inspection

Supports various authenticity features such as ultraviolet light feature inspection, infrared light feature inspection, chip data inspection, OCR data and electronic chip content cross-validation

Automatic Trigger, Automatic Reading and Classification

RFID reading supports automatic identification and classification of multiple certificates, automatic reading of certificate information and entry of certificate information into the system

Recognition of barcode and QR code

Passport reader supports identification of barcode and QR code (including mobile QR code)

Certificate reading within few seconds, high accuracy

The e-passport card reading time is less than 3 seconds, the second-generation card reading time is less than 1 second, the identification accuracy rate of the document is as high as 99.8%, and the communication rate supports up to 848 Kbps

Support secondary development

Provide software development packages for windows, Linux and Android systems for secondary development; Provide calling routines in VC, VB, c#, Java and other languages

Anti-glare Interference

Remove the influence of anti-counterfeiting film and reflections to ensure that the color of the document is not distorted

System compatibility and strong applicability

It can be embedded in various self-service devices such as security gates, self-service ticket machines, VTM, digital currency exchange machines, etc., used in hotels, travel agencies, visitor management systems, airports, high-speed rail, customs, inspection and quarantine, diplomacy, public security, exhibitions, etc. Multiple scenarios

Product Superiority

Support Xinchuang PC operating system
The passport reader supports chips such as Feiteng, Loongson, and Megachip, as well as domestic systems such as Kirin System and Unison UOS, and the price is independent and controllable
Snap connection, high quality material selection
Silver gray collocation, exquisite and compact, curve design, full buckle connection, solid quality, 15 ° passport guide slot, professional high borosilicate glass, material selection, friction resistance, strong stability
Independent research and development, safe and reliable
OCR certificate recognition, embedded software development, structural design, RFID card reading and debugging, image forgery detection and other completely independent research and development, safe and reliable
Anti-metal and signal interference
Dual antenna design to prevent signal interference, anti-metal interference, can be integrated into various metal equipment
Flexible reading mode configuration
Under different reading modes, the card reading rate, the displayed text information and picture information are different, which are flexibly configured and suitable for different scenarios.
Qualified enterprise with strong strength
Passed various industry certifications such as TravelSky certification, inspection report of the Ministry of Public Security, information security management system certification, and international certifications such as CE and FCC
Customizable services
Passport readers can add new types of documents to identify different countries according to different needs of customers
HD shooting and clear perspective
Passport reader 5 megapixel high-definition imaging, physical resolution of 500dpi, dual light sources to remove the impact of light spots
Various models
Including kiosk KR500(C)、KR200(C)、KR100(C) passport readers to meet different customer needs

Application Scenarios

  • Digital Currency
  • Immigration Administration
  • Customs Clearance
  • Tourism Industry
  • Self-Service Customs Clearance
  • High Speed Rail
Digital Currency

When the digital currency is officially launched in the future, a digital currency exchange machine will be launched, and the Sinosecu card reader will be integrated into the digital currency exchange machine. After domestic and foreign users present second-generation ID cards, passports and other identity documents to the digital currency exchange machine to pass real-name authentication, It can realize various exchange methods such as exchanging foreign bank cards for RMB, exchanging foreign currency for NFC cards, exchanging cash/bank cards to personal real-name digital currency accounts, etc., which is convenient for people who use cash and bank cards and foreign friends to exchange, and the passport reader automatically collects card information, conduct personal identification inspection, help banks improve the efficiency of real-name authentication, facilitate domestic and foreign users to realize free consumption, reduce waiting time in line, and prevent forged and fake documents from being exchanged for digital currency.

Immigration Administration

The Sinosecu card reader is applied to the self-service application machines and self-service certificate issuing machines in the entry-exit halls of public security bureaus in various places. When the public handles entry-exit certificates and certificate collection business, they put passports and other identity documents on the machine, and the passport reader automatically recognizes them. Certificate information, improve the efficiency of certificate processing and evidence collection, and reduce the error rate at the same time.

Customs Clearance

When international passengers enter China, their luggage needs to be checked by an X-ray machine. After the luggage is checked by the X-ray machine, passengers who need to open the bag for re-inspection must register passport and other valid certificate information; Cash will be restricted, and real-name registration must be carried out in order to prevent passengers from carrying excessive items; manual inspection and registration of document information is time-consuming, laborious, and error-prone. The Sinosecu passport reader is integrated at the customs entry-exit port to help the customs clearance industry complete entry-exit with high efficiency Inspection, while saving manpower management costs and improving the level of "intelligent" management.

Tourism Industry

Sinosecu Card Reader can recognize a wide variety of documents, including ID cards, passports, Hong Kong, Macao and Taiwan travel permits, and home return permits. After integrated applications in scenic spots, tourists only need to purchase tickets online with their real names. After the scenic spot, you can directly swipe your ID to enter the scenic spot through the passport reader, and promote the smooth development of the real-name system ticket purchase in the scenic spot.

Self-Service Customs Clearance

After purchasing a ticket at a long-distance bus station, the passenger passes through the customs with valid documents such as the ticket and ID card, passport, Mainland Permit, and Taiwan compatriots card. After passing through, the gates will be punched automatically, and passengers will enter the station to board the train, reducing the waiting time in line.

High Speed Rail

Integrate the Sinosecu card reader into the self-service ticket vending machine at the high-speed rail station. Domestic and foreign passengers can use ID cards, passports, military officer certificates, home-return certificates, and second-generation Taiwan compatriot certificates. The self-service ticket vending machines at high-speed rail stations are efficient. Complete ticket purchase or ticket collection.

Case

How does Traditional Hotels Transform into Smart Hotels
The Combination and Verification of Person and Document in the Hotel
ID Card Reader Increases Hotel Occupancy

Product parameters

  • KR160 Passport Scanner
    RFID Reading OCR Processing Visible Image IR Image UV Image Auto-Trigger
    - √ √ √ - √
    Detalis
    Illumination sources Visible, IR(850nm)
    Anti-glare Elimination of glare from holographic anti-counterfeiting film and reflection of light
    Image Acquisition Active scan area: 127mm x 88mm
    CMOS, 500 Megapixels (2592*1944)
    Imaging Color Depth: 24 bits/pixels
    Resolution: 500 DPI
    Image Format: JPEG, BMP, PNG
    Crop for Headshot Cropping of a document headshot image from a general image
    OCR Recognition Support extract data and image from ICAO 9303 Standard compliant documents and other Non-ICAO 9303 Standard compliant document, like ID card, Driver's License, Exit-entry Permit to HK/Macau, and etc by OCR
    Barcode:
    1D: Code 128, Code 39, EAN-13, and etc
    2D: PDF417, QR, DataMatrix™, and etc
    Scanning speed less than 1 second
    RFID Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B)
    Support e-passport Basic Access Control(BAC)
    Support active/passive authentication
    Machine Readable Zone ICAO 9303 Standard compliant documents:
    ID-1
    ID-2
    ID-3
    Non-ICAO 9303 Standard compliant documents issued by China
    IP Rating IP50
    Data Communication Compatible USB 2.0, USB 3.0, PC/SC
    Communication Speed Up to 848kbps
    Auto-trigger Automatic detection of a document in a scanning area
    Auto-classification Automatic recognition of a ID document type
    Status Indicators Four status indicator LEDs (for Power, Ready, Error, and Warning)
    Support customize indicators
    Sound Buzzer
    Software Complete OCR SDK including DLLs, OCXs, Websocket, and Demo program
    Programming Language:
    VC, VB, C#, Java, etc. Provide OCR SDK for Linux.
    Power Input AC 100~240V 50~60Hz, 0.8A
    Output: DC 12V, 2A
    Environmental Humidity: 20% to 95% non-condensing
    Temperature:
    Operating: -10ºC to 50ºC
    Storage: -20ºC to 50ºC
    OS compatibility Windows® 2000-SP4  ，Windows® XP  ，Windows® Vista, Windows®7, Windows®8, Windows®10, and Linux®
    Hardware Dimension: 193.2*166*104.3mm
    Net Weight: 1.30Kg  Gross Weight: 2.11Kg
    Warranty 1 year warrany, extensible
  • KR420 Passport Scanner
    RFID Reading OCR Processing Visible Image IR Image UV Image Auto-Trigger
    √ √ √ √ - √
    Detalis
    Illumination sources Visible, IR(850nm)
    Anti-glare Elimination of glare from holographic anti-counterfeiting film and reflection of light
    Image Acquisition Active scan area: 127mm x 88mm
    CMOS, 500 Megapixels (2592*1944)
    Imaging Color Depth: 24 bits/pixels
    Resolution: 500 DPI
    Image Format: JPEG, BMP, PNG
    Get the headshot from the chip
    Crop for Headshot Cropping of a document headshot image from a general image
    OCR Recognition Support extract data and image from ICAO 9303 Standard compliant documents and other Non-ICAO 9303 Standard compliant document, like ID card, Driver's License, Exit-entry Permit to HK/Macau, and etc by OCR
    Barcode:
    1D: Code 128, Code 39, EAN-13, and etc
    2D: PDF417, QR, DataMatrix™, and etc
    Scanning speed less than 1 second
    RFID Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B)
    Support e-passport Basic Access Control(BAC)
    Support active/passive authentication
    Machine Readable Zone ICAO 9303 Standard compliant documents:
    ID-1
    ID-2
    ID-3
    Non-ICAO 9303 Standard compliant documents issued by China
    IP Rating IP50
    Data Communication Compatible USB 2.0, USB 3.0, PC/SC
    Communication Speed Up to 848kbps
    Auto-trigger Automatic detection of a document in a scanning area
    Auto-classification Automatic recognition of a ID document type
    Status Indicators Four status indicator LEDs (for Power, Ready, Error, and Warning)
    Support customize indicators
    Sound Buzzer
    Software Complete OCR SDK including DLLs, OCXs, Websocket, and Demo program
    Programming Language:
    VC, VB, C#, Java, etc. Provide OCR SDK for Linux.
    Power Input AC 100~240V 50~60Hz, 0.8A
    Output: DC 12V, 2A
    Environmental Humidity: 20% to 95% non-condensing
    Temperature:
    Operating: -10ºC to 50ºC
    Storage: -20ºC to 50ºC
    OS compatibility Windows® 2000-SP4  ，Windows® XP  ，Windows® Vista, Windows®7, Windows®8, Windows®10, and Linux®
    Hardware Dimension: 193.2*166*104.3mm
    Net Weight: 1.30Kg  Gross Weight: 2.11Kg
    Warranty 1 year warrany, extensible
  • KR530 Passport Scanner
    RFID Reading OCR Processing Visible Image IR Image UV Image Auto-Trigger
    √ √ √ √ √ √
    Detalis
    Illumination sources Visible, IR(850nm), UV(365nm)
    Anti-glare Elimination of glare from holographic anti-counterfeiting film and reflection of light
    Image Acquisition Active scan area: 127mm x 88mm
    CMOS, 500 Megapixels (2592*1944)
    Imaging Color Depth: 24 bits/pixels
    Resolution: 500 DPI
    Image Format: JPEG, BMP, PNG
    Get the headshot from the chip
    Crop for Headshot Cropping of a document headshot image from a general image
    OCR Recognition Support extract data and image from ICAO 9303 Standard compliant documents and other Non-ICAO 9303 Standard compliant document, like ID card, Driver's License, Exit-entry Permit to HK/Macau, and etc by OCR
    Barcode:
    1D: Code 128, Code 39, EAN-13, and etc
    2D: PDF417, QR, DataMatrix™, and etc
    Scanning speed less than 1 second
    RFID Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B)
    Support e-passport Basic Access Control(BAC)
    Support active/passive authentication
    Machine Readable Zone ICAO 9303 Standard compliant documents:
    ID-1
    ID-2
    ID-3
    Non-ICAO 9303 Standard compliant documents issued by China
    IP Rating IP50
    Data Communication Compatible USB 2.0, USB 3.0, PC/SC
    Communication Speed Up to 848kbps
    Auto-trigger Automatic detection of a document in a scanning area
    Auto-classification Automatic recognition of a ID document type
    Status Indicators Four status indicator LEDs (for Power, Ready, Error, and Warning)
    Support customize indicators
    Sound Buzzer
    Software Complete OCR SDK including DLLs, OCXs, Websocket, and Demo program
    Programming Language:
    VC, VB, C#, Java, etc. Provide OCR SDK for Linux.
    Power Input AC 100~240V 50~60Hz, 0.8A
    Output: DC 12V, 2A
    Environmental Humidity: 20% to 95% non-condensing
    Temperature:
    Operating: -10ºC to 50ºC
    Storage: -20ºC to 50ºC
    OS compatibility Windows® 2000-SP4  ，Windows® XP  ，Windows® Vista, Windows®7, Windows®8, Windows®10, and Linux®
    Hardware Dimension: 193.2*166*104.3mm
    Net Weight: 1.30Kg  Gross Weight: 2.11Kg
    Warranty 1 year warrany, extensible
  • KR530(B) Passport Scanner
    RFID Reading OCR Processing Visible Image IR Image UV Image Auto-Trigger
    — √ √ √ √ √
    Detalis
    Illumination sources Visible, IR(850nm), UV(365nm)
    Anti-glare Elimination of glare from holographic anti-counterfeiting film and reflection of light
    Image Acquisition Active scan area: 127mm x 88mm
    CMOS, 500 Megapixels (2592*1944)
    Imaging Color Depth: 24 bits/pixels
    Resolution: 500 DPI
    Image Format: JPEG, BMP, PNG
    Get the headshot from the chip
    Crop for Headshot Cropping of a document headshot image from a general image
    OCR Recognition Support extract data and image from ICAO 9303 Standard compliant documents and other Non-ICAO 9303 Standard compliant document, like ID card, Driver's License, Exit-entry Permit to HK/Macau, and etc by OCR
    Barcode:
    1D: Code 128, Code 39, EAN-13, and etc
    2D: PDF417, QR, DataMatrix™, and etc
    Scanning speed less than 1 second
    RFID

    Read Smart Card complied with ISO/IEC 7816
    Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B)
    Support e-passport Basic Access Control(BAC)
    Support active/passive authentication
    QR Code Recognition and

    Decoding

    Read barcodes on printed paper tickets and electronic tickets
    Machine Readable Zone ICAO 9303 Standard compliant documents:
    ID-1
    ID-2
    ID-3
    Non-ICAO 9303 Standard compliant documents issued by China
    IP Rating IP50
    Data Communication Compatible USB 2.0, USB 3.0, PC/SC
    Communication Speed Up to 848kbps
    Auto-trigger Automatic detection of a document in a scanning area
    Auto-classification Automatic recognition of a ID document type
    Status Indicators Four status indicator LEDs (for Power, Ready, Error, and Warning)
    Support customize indicators
    Sound Buzzer
    Software Complete OCR SDK including DLLs, OCXs, Websocket, and Demo program
    Programming Language:
    VC, VB, C#, Java, etc. Provide OCR SDK for Linux.
    Power Input AC 100~240V 50~60Hz, 0.8A
    Output: DC 12V, 2A
    Environmental Humidity: 20% to 95% non-condensing
    Temperature:
    Operating: -10ºC to 50ºC
    Storage: -20ºC to 50ºC
    OS compatibility Windows® 2000-SP4  ，Windows® XP  ，Windows® Vista, Windows®7, Windows®8, Windows®10, and Linux®
    Hardware Dimension: 169*193*104.3mm
    Net Weight: 1.30Kg  Gross Weight: 2.11Kg
    Warranty 1 year warrany, extensible
  • KR500(C) ID Card Scanner
    RFID Reading OCR Processing Visible Image IR Image UV Image Auto-Trigger
    √ √ √ √ √ √
    Detalis
    Illumination sources Visible, IR(850nm), UV(365nm)
    Anti-glare Elimination of glare from holographic anti-counterfeiting film and reflection of light
    Image Acquisition Active scan area: 127mm x 88mm
    CMOS, 500 Megapixels (2592*1944)
    Imaging Color Depth: 24 bits/pixels
    Resolution: 500 DPI
    Image Format: JPEG, BMP, PNG
    Get the headshot from the chip
    Crop for Headshot Cropping of a document headshot image from a general image
    OCR Recognition Support extract data and image from ICAO 9303 Standard compliant documents and other Non-ICAO 9303 Standard compliant document, like ID card, Driver's License, Exit-entry Permit to HK/Macau, and etc by OCR
    Barcode:
    1D: Code 128, Code 39, EAN-13, and etc
    2D: PDF417, QR, DataMatrix™, and etc
    Scanning speed less than 1 second
    RFID

    Read Smart Card complied with ISO/IEC 7816
    Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B)
    Support e-passport Basic Access Control(BAC)
    Support active/passive authentication
    Machine Readable Zone ICAO 9303 Standard compliant documents:
    ID-1
    ID-2
    ID-3
    Non-ICAO 9303 Standard compliant documents issued by China
    IP Rating IP50
    Data Communication Compatible USB 2.0, USB 3.0, PC/SC
    Communication Speed Up to 848kbps
    Auto-trigger Automatic detection of a document in a scanning area
    Auto-classification Automatic recognition of a ID document type
    Status Indicators Four status indicator LEDs (for Power, Ready, Error, and Warning)
    Support customize indicators
    Sound Buzzer
    Software Complete OCR SDK including DLLs, OCXs, Websocket, and Demo program
    Programming Language:
    VC, VB, C#, Java, etc. Provide OCR SDK for Linux.
    Power Input AC 100~240V 50~60Hz, 0.8A
    Output: DC 12V, 2A
    Environmental Humidity: 20% to 95% non-condensing
    Temperature:
    Operating: -10ºC to 50ºC
    Storage: -20ºC to 50ºC
    OS compatibility Windows® 2000-SP4  ，Windows® XP  ，Windows® Vista, Windows®7, Windows®8, Windows®10, and Linux®
    Hardware Dimension: 169*193*104.3mm
    Net Weight: 1.30Kg  Gross Weight: 2.11Kg
    Warranty 1 year warrany, extensible
